shenzhen, china oct. 13, 2023 — gigalight, through its open optical network lab, is excited to announce the successful deployment of single-lambda 400g dci box network systems for international data center and telecommunications operator clients. this cutting-edge system leverages the latest 400g qsfp dd zr/zr coherent optical modules and is housed in a 2u chassis, offering a remarkable maximum transmission capacity of 6.4t. this innovative solution is built around a white box design.

key system features:

capacity and form factor

• a 2u standalone chassis can support a maximum capacity of 6.4t, with options for 1u and 2u chassis.

use cases

• primarily designed for data center interconnect (dci) and metro network wdm/backbone wdm, providing a white box transmission platform.

design advantages:

• the product emphasizes white box design and simplified architecture.
• a hybrid design of optical and electrical layers effectively saves data center space and facilitates bandwidth expansion.
• supports snmp-based graphical management interface for intuitive fault localization.

cooling and redundancy

• utilizes a front-to-rear airflow design, combined with multiple sets of high-speed redundant fans and power supplies, ensuring outstanding cooling performance.

hardware support

• optical layer: supports raman, edfa, wss, and op cards, among others.
• electrical layer: line-side supports 100g/200g/400g coherent cards, while client-side supports 10ge/25ge/100ge/400ge.

network management

• supports snmp/netconf protocols, cli/web/bs management, dual main control backup, and osc communication.
• boasts robust transmission and network management capabilities, making it especially suitable for data center dci and metropolitan network applications.

business cards

400g qsfp-dd dco muxponder

this is the first business card introduced by gigalight in china. the line-side port supports cost-effective 400g qsfp-dd dco zr/zr , while the customer side supports 4x100ge qsfp28 ports, meeting the needs of dci interconnect scenario applications.

800g transponder 1/4 business card

with up to 800g bandwidth, featuring support for two 400g cfp2 dco on the line side and 2x400g qsfp-dd ports on the customer side, catering to high-bandwidth dci applications.

400g qsfp-dd dco zr coherent module

supports single-wavelength 400g dwdm, adjustable tx optical power from 0 to -6dbm, flexible grid, and openzr protocol. it utilizes ofec, offers excellent interoperability, achieves an rx osnr of 24db/0.1nm @ 400g 16qam, meets the requirements for 300km to 400km service interconnections, and has a typical power consumption of less than 22w.

gigalight is one of the openzr members. the company boasts significant technical expertise in the coherent optical module field. gigalight’s open optical network lab has conducted comprehensive integration and fundamental research on opendci box. since entering the coherent wavelength division transmission system business, gigalight has successfully implemented network and transmission services based on 200g and 400g coherent optical modules for several overseas customers. this has led to the accumulation of extensive experience in overseas customer installation and maintenance

about gigalight

as an open optical networking explorer, gigalight integrates the design, manufacturing, and sales of both active and passive optical devices and subsystems. the company’s product portfolio includes optical modules, silicon photonics modules, liquid-cooled modules, passive optical components, active optical cables, direct attach copper cables, coherent optical communication modules, and open dci box subsystems. gigalight focuses on serving applications such as data centers, 5g transport networks, metropolitan wdm transmission, ultra-hd broadcast and video, and more. it stands as an innovative designer of high-speed optical interconnect hardware solutions.

[shenzhen, china, september 22, 2023] gigalight, the open optical networking devices explorer, is excited to announce the successful development of a 400g qsfp-dd lr4 10km optical module based on silicon photonics technology. this groundbreaking product will be featured in a live demonstration at the 49th ecoc exhibition from october 2-4, 2023 (booth no.: 553).

gigalight’s silicon-based 400g qsfp-dd lr4 10km product fully adheres to the 400g-lr4-10 100g lambda msa standards, supporting single-mode fiber transmission of up to 10km while maintaining backward compatibility with 400g fr4 applications. this product features dual lc fiber connectors and employs the cwdm4 wavelength. both the transmitter and receiver sides of the product utilize cutting-edge silicon photonics technology.

key performance attributes include:

• tx oma optical power exceeding 0.3dbm.
• tx per-channel tdecq of less than 2.4db.
• rx oma sensitivity meeting -6.8dbm @ 2.4e-4 pre-fec 53.125gbd.
• power consumption of less than 11w.

this product underwent a continuous 24-hour, 10km optical fiber transmission test in a 400ge traffic benchmark, achieving zero data loss with the assistance of kp4 fec. gigalight plans to commence mass production of this product before the end of the current year.

breaking new ground often involves navigating challenges. as the second global manufacturer to launch this module, after intel, gigalight has dedicated seven years to advancing the field of silicon photonics. we extend our heartfelt appreciation to all those who’ve stood by us through the demanding phases of this journey. thanks to your steadfast support, silicon photonics has emerged from a formidable landscape into a promising frontier.

about gigalight

as an open optical networking explorer, gigalight integrates the design, manufacturing, and sales of both active and passive optical devices and subsystems. the company’s product portfolio includes optical modules, silicon photonics modules, liquid-cooled modules, passive optical components, active optical cables, direct attach copper cables, coherent optical communication modules, and open dci box subsystems. gigalight focuses on serving applications such as data centers, 5g transport networks, metropolitan wdm transmission, ultra-hd broadcast and video, and more. it stands as an innovative designer of high-speed optical interconnect hardware solutions.

[shenzhen, china, september 13, 2023] pursuing the optimal 400g data center configuration has always been a hot topic and focus in the industry. gigalight recently announced the launch of a 400g qsfp-dd 2×fr4 data center optical module based on the 50g pam4 dml technology platform, providing a new option for customers’ data center architectures.

the key difference between the newly launched and the previous lies in the fact that the 400g 2×fr4 optical port supports 8×50g pam4, while the 400g fr4 optical port supports 4×100g pam4. additionally, the 400g qsfp-dd 2×fr4 has networking advantages. it uses duplex dual lc optical interfaces, supporting the fan-out of two 200g qsfp56 optical modules, enabling a direct transition from 200g data centers to 400g data centers.

the networking architecture is as follows:

furthermore, the 400g qsfp-dd 2×fr4, utilizing the 50g pam4 dml technology platform, also has advantages in terms of cost structure and power consumption. its main optoelectronic characteristics are as follows.

eye diagram and sensitivity indicators:

• tdecq per channel is less than the protocol specification of 3.1db.
• rxsens (oma) sensitivity is better than -5.5dbm @ 2.4e-4 pre-fec 26.5625gbd pam4.
• maximum power consumption of the optical module is less than 9w.

with the maturity of dml technology, cost-effective 400g data center solutions are moving towards maturity and commercialization. leveraging the fusion of existing 7nm dsp technology and dml technology enables more efficient and cost-effective processing, transmission, and reception of data. this helps reduce the unit bit power consumption, making data centers more energy-efficient and cost-effective. gigalight will continue to delve into research and development, providing customers with even better internal data center interconnection solutions.

about gigalight

as an open optical networking explorer, gigalight integrates the design, manufacturing, and sales of both active and passive optical devices and subsystems. the company’s product portfolio includes optical modules, silicon photonics modules, liquid-cooled modules, passive optical components, active optical cables, direct attach copper cables, coherent optical communication modules, and open dci box subsystems. gigalight focuses on serving applications such as data centers, 5g transport networks, metropolitan wdm transmission, ultra-hd broadcast and video, and more. it stands as an innovative designer of high-speed optical interconnect hardware solutions.

[shenzhen, china, september 13, 2023] the ibc event is scheduled to take place from september 15th to 18th at the rai amsterdam convention center. gigalight, the open optical network device explorer, will be introducing its second-generation mini 48g-sdi (4x12g) broadcast-grade video optical transceiver kit solution at booth 5.b55 (amsterdam). we extend a warm invitation to our industry colleagues to join us.

in today’s world, 8k represents the pinnacle of television standards, and it’s recognized as the “key technology” for dominating the media landscape. achieving a 12-bit color depth at 8k resolution is a monumental challenge for manufacturers. it not only demands rigorous adherence to hdr standards but also necessitates a significant jump in near-field transmission bandwidth, from 18g to 48g.

gigalight’s revolutionary 48g-sdi (4×12g) broadcast-grade video optical transceiver kit solution ingeniously integrates four optical extenders and four 12g sdi optical modules with a wavelength division multiplexer into a single package. this enables an all-in-one application that can transmit four uncompressed 12g-sdi signals over a remarkable 20km span of single-mode optical fiber. this empowers users with the ability to deploy uncompressed 8k sdi baseband optical connections over extended distances swiftly. our solution finds applications in various dynamic settings, including broadcast television stations, outdoor sports events, large-scale live stage productions, outdoor live broadcasts, and more.

this new launch second-generation 8k 48g sdi solution comprises a mini 48g extender with a qsfp optical interface and a 48g sdi qsfp psm pluggable optical module. this solution boasts high integration and offers the flexibility needed for deployments. the mini optical extender features high-quality hd-bnc interfaces and incorporates 12g-sdi cdr clock data recovery chips to ensure impeccable signal quality.

the 48g sdi qsfp psm4 pluggable optical module meets the stringent requirement of error-free transmission over 20km. it employs gigalight’s pioneering 4x mini-tosa high-reliability optical device solution, complemented by low-power dml lasers, and supports four parallel 3g-sdi/12g-sdi signals. the optical interface uses mpo-12, and the module’s power consumption is under 4w. furthermore, for customers with specific needs, it can be tailored for cwdm4 wavelengths and can be transmitted through a single optical fiber after multiplexing using an external cwdm4 multiplexer.

here are the key parameters of gigalight’s second-generation 8k 48g sdi optical transmission product:

• supports resolutions of up to 2160p/60hz per channel
• each channel undergoes individual retiming (cdr)
• compatible with various formats, including
  • smpte st 2082-1 (11.88gbps/s)
  • smpte st 2081-1 (5.94gbps/s)
  • smpte st 424 (2.97gbps/s)
  • smpte st 292 (1.485gbps/s)
  • smpte st 259 (360mb/s)
  • dvb-asi (270mb/s)
  • madi (125mb/s)
• transmitter equipped with a built-in coaxial cable equalizer:
  • 70m at 11.88gb/s: <0.2ui output jitter
  • 90m at 5.94gb/s: <0.15ui output jitter
  • 180m at 2.97gb/s: <0.1ui output jitter
  • 240m at 1.485gb/s: <0.1ui output jitter
  • 300m at 270mb/s: <0.1ui output jitter

gigalight stands as one of the pioneering developers and leaders in the global sdi video and high-speed broadcasting optical transmission arena. discover gigalight and embark on a journey into the new world of next-generation broadcasting optical networks.

about ibc

ibc stands as the pinnacle of global content and technology gatherings. it unites professionals from the realms of media, entertainment, and technology in an electrifying live event that empowers every participant to access crucial insights, share their expertise, and open doors to countless business opportunities. ibc was conceived “by the industry, for the industry,” a fundamental principle since its inception in 1967 that still holds true today. over its impressive 56-year history, ibc has consistently adapted to embrace emerging trends and technologies. from its inaugural year, which attracted representatives from 24 countries, ibc has grown to be a global phenomenon, now hosting exhibitors, speakers, and attendees from over 170 nations.

[shenzhen, china, sep 11, 2023]the open data center committee summit (odcc) 2023 is scheduled to be held from september 13th to 14th at the beijing international convention center. gigalight, an open optical network devices explorer, will be showcasing a range of original interconnection technology solutions, including silicon photonics and immersion cooling.

as odcc continues to expand, gigalight has successfully transitioned concepts into tangible products with a variety of original interconnection technologies, including:

400g/800g series

400g/800g silicon photonics optical modules

gigalight’s 400g/800g series leverages its research and development capabilities, unwavering dedication, and support from the silicon photonics industry chain. these modules align seamlessly with silicon photonics technology and 100g pam4 technology, offering data center networks a reliable performance and a foundation for long-term scalability.

• 400g qsfp-dd dr4/dr4 500m/2km
• 400g qsfp-dd fr4 2km
• 400g qsfp112 dr4/dr4 500m/2km
• 800g qsfp-dd dr8/dr8 500m/2km

400g/800g vcsel series

this series features high-performance 112gbps vcsel lasers and 7nm dsp. the electrical host interface supports 112gbps pam4 signals per channel, complying with cmis 4.0 protocol standards.

• 400g qsfp112 sr4/aoc
• 400g osfp112 sr4/aoc
• 800g qsfp-dd sr8/aoc
• 800g osfp sr8/aoc

100g/200g immersion cooling series

to address the burgeoning market demand for liquid-cooled data centers, gigalight has introduced highly reliable and cost-effective immersion-cooled optical modules. these modules employ a direct immersion cooling method with optimized optical device sealing to prevent cooling liquid from entering the optical path, effectively mitigating any adverse effects on the optical path

• 100g qsfp28 psm4 2km
• 100g qsfp28 sr4/aoc 100m/300m
• 200g qsfp56 sr4/aoc 100m

100g triple-proof series

furthermore, gigalight has developed industry-leading “anti-condensation, anti-moisture, and anti-corrosion” triple-proof optical modules tailored for specific demanding application scenarios. these modules employ advanced processes, including “paralyne vacuum coating” and “3m coating,” to provide dual protection, ensuring they can thrive even in the harshest environmental conditions.

• 100g qsfp28 sr4 70m/100m
• 100g qsfp28 psm4 2km
• 100g qsfp28 cwdm4 2km

odcc serves as the broadest stage in the data center field, and gigalight extends a warm invitation to industry colleagues to visit our booth and experience our advanced technologies and solutions firsthand.

about gigalight

as an open optical networking explorer, gigalight integrates the design, manufacturing, and sales of both active and passive optical devices and subsystems. the company’s product portfolio includes optical modules, silicon photonics modules, liquid-cooled modules, passive optical components, active optical cables, direct attach copper cables, coherent optical communication modules, and open dci box subsystems. gigalight focuses on serving applications such as data centers, 5g transport networks, metropolitan wdm transmission, ultra-hd broadcast and video, and more. it stands as an innovative designer of high-speed optical interconnect hardware solutions.

[shenzhen, china, august 22, 2023] open optical network devices explorer — gigalight, on the occasion of the qixi festival, announces the launch of 800g qsfp-dd vr8/sr8, 800g osfp vr8/sr8, 400g qsfp112 vr4/sr4, and 400g osfp112 vr4/sr4 optical modules, along with active optical cables. this product series is equipped with high-performance 112gbps vcsel lasers and 7nm dsp technology. the electrical host interface supports 112gbps pam4 signals per channel, in compliance with cmis 4.0 protocol.

key performance highlights

eye diagram and sensitivity metrics tdecq

per channel is less than 3db; oma rxsen sensitivity meets -5.2dbm @ 2.4e-4 pre-fec 53.125gbd.

transmission distances

vr8/vr4 supports transmission distances of 30 meters (om3 mmf) and 50 meters (om4 mmf).

sr8/sr4 supports transmission distances of 60 meters (om3 mmf) and 100 meters (om4 mmf).

form factors

400g/800g optical modules support two form factor: qsfp-dd and osfp.

power consumption design

power consumption is less than 14w for 800g optical modules/aocs, and less than 8w for 400g optical modules/aocs.

the complete product lineup of this series includes:

800g (8x112g) mmf products

400g (4x112g) mmf products

• )

about gigalight

as an open optical networking explorer, gigalight integrates the design, manufacturing, and sales of both active and passive optical devices and subsystems. the company’s product portfolio includes optical modules, silicon photonics modules, liquid-cooled modules, passive optical components, active optical cables, direct attach copper cables, coherent optical communication modules, and open dci box subsystems. gigalight focuses on serving applications such as data centers, 5g transport networks, metropolitan wdm transmission, ultra-hd broadcast and video, and more. it stands as an innovative designer of high-speed optical interconnect hardware solutions.

shenzhen, china, august 17, 2023 – shenzhen gigalight technology co., ltd. has announced the successful development of an 800g qsfp-dd dr8 500m/dr8 2km/dr8 10km optical module based on silicon photonics technology. the company will showcase the product’s performance through live demos at the cioe event (booth 11a71) from september 6th to 8th, 2023. visitors are warmly invited to attend and provide their guidance.

gigalight’s 800g qsfp-dd dr8 10km silicon photonics module employs four 1310nm cw lasers. it features a maximum power consumption of less than 18w, tdecq below 2db, and supports 8 lanes of 100g pam4 optical signals. this module meets the 10km dual-fiber transmission requirement and achieves an oma rxsen of -7.1dbm @ 2.4e-4 pre-fec 53.125gbd, exceeding the 500-meter link budget specified by ieee 802.3. the module successfully completed a 10km optical fiber loopback test for 24 hours with no packet loss when operating at 800ge traffic rates with kp4 fec enabled. the current released version supports both mpo16/apc and dual mpo12/apc connector architectures. in comparison to conventional 800g optical modules using the 8-lane eml solution, the silicon photonics module employs fewer lasers, allowing, for instance, the 800g dr8 to achieve lower power consumption with improved performance.

with the ongoing trend of ai high computing power, gigalight, benefiting from its r&d strength, persistent efforts, and support from the silicon photonics industry chain, has overcome all key bottlenecks in silicon photonics technology. it is believed that more silicon photonics products will be released, fostering resonance among the industry chain and customers.

about gigalight

as an open optical networking explorer, gigalight integrates the design, manufacturing, and sales of both active and passive optical devices and subsystems. the company’s product portfolio includes optical modules, silicon photonics modules, liquid-cooled modules, passive optical components, active optical cables, direct attach copper cables, coherent optical communication modules, and open dci box subsystems. gigalight focuses on serving applications such as data centers, 5g transport networks, metropolitan wdm transmission, ultra-hd broadcast and video, and more. it stands as an innovative designer of high-speed optical interconnect hardware solutions.
